PEQVI Series 3000 Oil BDV Test Set – Instruction Manual (OTS-3060 / OTS-3080 / OTS-3100)

PEQVI® Series 3000 Oil BDV Test Set

Instruction Manual – Digital PDF

The PEQVI® Series 3000 Oil BDV Test Set Instruction Manual provides operating, safety, testing, maintenance, and troubleshooting information for the Series 3000 range of oil dielectric breakdown voltage (BDV) test sets.

The manual is applicable to the OTS-3060, OTS-3080, and OTS-3100 models, covering test voltage ratings from 60 kV to 100 kV.

Compatible Models

What's Included

• PEQVI® Series 3000 Oil BDV Test Set Instruction Manual
• Safety and operating instructions
• Oil BDV testing procedure guidance
• Controls and display information
• Operating instructions for Series 3000 models
• Maintenance and troubleshooting information
• Technical information and operating precautions

Digital Product

This is a digital product. No physical manual or test set will be shipped.

The instruction manual is provided in PDF format for convenient digital access and reference.

Safety Information

Oil BDV testing involves high voltage. The Series 3000 Oil BDV Test Set must only be operated by suitably trained and authorized personnel who understand the hazards associated with high-voltage electrical testing.

Read and understand all safety instructions and operating procedures before using the test set.

Document Details

Compatibility Note

This manual is applicable to the PEQVI® Series 3000 Oil BDV Test Set range comprising the OTS-3060 (60 kV), OTS-3080 (80 kV), and OTS-3100 (100 kV) models. Always refer to the model and rating information on your individual test set to determine the applicable voltage rating.

PEQVI® – Piyush Electronics & Electricals (P) Ltd.

Manufacturer of Oil BDV Test Sets and Electrical Test Equipment
